| Make | Model | Engine | Year |
|---|---|---|---|
| Volkswagen | Passat | — | 2015 |
| Volkswagen | Passat | 1968cc, 2.0L L4 | 2012, 2013, 2014 |
| Volkswagen | PASSAT | 2.0L, Diesel | 2012, 2013, 2014 |
| Volkswagen Car | Passat | L4 2.0L 1968CC 120CID | 2015 |
| Volkswagen Car | Passat | L4 2.0L 1968CC 120CID | 2012-2014 |
| Lester | 11563 |
| Manufacture | DENSO (Not OEM) |
| Volt | 12 |
| Amps | 180 |
| Regulator Clock | 2:00 |
| Rotation Direction | Clockwise (Right) |
| Mount Hole ID 1 | 8.600mm |
| Mount Hole 1 Type | Unthreaded |
| Mount Hole ID 2 | 8.600mm |
| Mount Hole 2 Type | Unthreaded |
| Mount Hole ID 3 | M8-1.25 |
| Mount Hole 3 Type | Threaded |
| Mount Hole ID 4 | M8-1.25 |
| Mount Hole 4 Type | Threaded |
| Mounting Ear 2 Thickness | 14mm |
| Mounting Ear 3 Thickness | 20mm |
| Mounting Ear 4 Thickness | 20mm |
| Alt Mounting Foot Thickness | 14mm |
| Fan Location | Internal |
| Regulator Location | Internal |
| Terminal ID | B+ |
| Terminal Size | M8-1.25 |
| Terminal ID 2 | L |
| Terminal 2 Size | Spade |
| Terminal ID 3 | DFM |
| Terminal 3 Size | Spade |
| Polarity | Negative |
| Number of Grooves | 6 |
| Groove OD | 56mm |
| Pulley Type | Clutch Pulley |
| Pulley Outer Diameter | 61mm |
| Shaft | M16-1.5 |
| Decoupled Or Clutch Pulley | Yes |
| Fan Type | Internal |
| Plug Clock Rear View Main Mounting Ear At 6 O Clock | 6 |
| Pulley Belt Type | Serpentine |
| Pulley Groove Quantity | 6 |
| Regulator Type | External |
| Stator Type | Hairpin |
| Bosch | 0125811009, 0125811036, AL0892N, AL0892X, 0-125-811-009, 0-125-811-036, F-00E-100-567 |
| Bosch Aftermarket | AL0892N (New), AL0892X (Reman) |
| Lester | 11563 |
| Volkswagen | 03L903023R, 03L-903-023R, 03L903023RX, 03L-903-023RX |
| Volkswagen Group | 03L903023R, 03L903023RX |
| IAT | A11563 |
| J&N | 400-24348, 400-24357 |
| PIC | 220-5704 |
| SEG Automotive | 0125.811.036 |
| VM International | 38522329F |
| Voltux | V2-11563 |
| WAI | 11563N |
| Xpart Global | XAB11563 |
