| make | model | engine | years |
|---|---|---|---|
| Pontiac | Vibe Base | 1794cc, 1.8L L4 1ZZFE | 2005 |
| Pontiac | Vibe GT | 1795cc, 1.8L L4 2ZZGE | 2005 |
| Pontiac | VIBE | 1.8L | 2003, 2004, 2005, 2006, 2007, 2008 |
| Pontiac | Vibe | 1794cc, 1.8L L4 | 2003, 2004, 2005, 2006, 2007, 2008 |
| Pontiac | Vibe | 1794cc, 1.8L L4 1ZZFE | 2003, 2004, 2005, 2006, 2007, 2008 |
| Pontiac | Vibe | 1795cc, 1.8L L4 | 2003, 2004, 2005, 2006, 2007, 2008 |
| Pontiac | Vibe | 1795cc, 1.8L L4 2ZZGE | 2003, 2004, 2005, 2006 |
| Toyota | COROLLA | 1.8L | 2003, 2004, 2005, 2006, 2007, 2008 |
| Toyota | COROLLA | 1.8L | 2003, 2004, 2005, 2006, 2007, 2008 |
| Toyota | Corolla | 1794cc, 1.8L L4 | 2003, 2003, 2004, 2004, 2005, 2005, 2006, 2006, 2007, 2007, 2008, 2008 |
| Toyota | Corolla | 1794cc, 1.8L L4 | 2003, 2004, 2005, 2006, 2007, 2008 |
| Toyota | Corolla | 1794cc, 1.8L L4 | 2003, 2004, 2005, 2006, 2007, 2008 |
| Toyota | Corolla | 1794cc, 1.8L L4 1ZZFE | 2003 |
| Toyota | Corolla | 1794cc, 1.8L L4 1ZZFE | 2003, 2004, 2005, 2006, 2007, 2008 |
| Toyota | Corolla | 1795cc, 1.8L L4 | 2005, 2006 |
| Toyota | Corolla | 1795cc, 1.8L L4 2ZZGE | 2005, 2006 |
| Toyota | MATRIX | 1.8L | 2003, 2004, 2005, 2006, 2007, 2008 |
| Toyota | Matrix | 1794cc, 1.8L L4 | 2003, 2004, 2005, 2006, 2007, 2008 |
| Toyota | Matrix | 1794cc, 1.8L L4 | 2003, 2004, 2005, 2006, 2007, 2008 |
| Toyota | Matrix | 1794cc, 1.8L L4 1ZZFE | 2003, 2004, 2005, 2006, 2007, 2008 |
| Toyota | Matrix | 1795cc, 1.8L L4 | 2003, 2004, 2005, 2006, 2007, 2008 |
| Toyota | Matrix | 1795cc, 1.8L L4 2ZZGE | 2003, 2004, 2005, 2006 |
| Toyota Car | Corolla | L4 1.8L 1794CC | 2003-2008 |
| Toyota Car | Corolla | L4 1.8L 1795CC | 2005-2006 |
| Lester | 17841 |
| Manufacture | DENSO (Not OEM) |
| Family | R5.0 |
| Volt | 12 |
| Power | 1.600 kw |
| HP | 2.146 |
| Rotation Direction | Clockwise (Right) |
| Electric Starter Type | Permanent Magnet Gear Reduction (PMGR) |
| Number of Teeth | 10 |
| Gear OD | 1.189" |
| Gear OD | 30.200mm |
| Mount Hole ID 1 | 11mm |
| Mount Hole 1 Type | Unthreaded |
| Mount Hole ID 2 | M10x1.25 |
| Mount Hole 2 Type | Threaded |
| Case Grounding | G |
| Design | PMGR |
| OE Manufacturer | DENSO |
| AC Delco Tools | 336-1768 |
| Arrowhead | ND280-0330, SND0295 |
| Bosch | SR3282X |
| Bosch Aftermarket | SR3282X (Reman) |
| Denso | 280-0330, 428000-0340, 428000-0341, 428000-1310, 428000-1311, 9642809-034, 428000-131 |
| General Motors | 88969483 |
| J&N Electrical Products | 410-52207 |
| Lester | 17841 |
| Toyota | 28100-0D080, 28100-22090, 28100-22090-84 |
| IAT | 610-17841 |
| PIC | 190-6144 |
| Remy | 17382 |
| Remy New | 99633 |
| WAI | 17841N, 17841R, 2-2360-ND |
| Xpart Global | XSD17841 |
