| Make | Model | Engine | Year |
|---|---|---|---|
| Land Rover | LR2 | 3.2L | 2008, 2009, 2010, 2011, 2012 |
| Land Rover | LR2 | 3192cc, 3.2L L6 | 2008, 2009, 2010, 2011 |
| Land Rover Truck | LR2 | L6 3.2L 3192CC | 2010 |
| Land Rover Truck | LR2 | L6 3.2L 3192CC | 2008, 2009, 2010, 2011, 2012 |
| Lester | 19095, 19179 |
| Volt | 12 |
| Power | 1.100 kw |
| HP | 1.475 |
| Condition | New |
| Rotation Direction | Clockwise (Right) |
| Electric Starter Type | Permanent Magnet Gear Reduction (PMGR) |
| Number of Teeth | 10 |
| Gear OD | 1.094" |
| Gear OD | 27.800mm |
| Length | 204.500 mm |
| Length | 8.051" |
| Mount Hole ID 1 | 10.500mm |
| Mount Hole 1 Type | Unthreaded |
| Mount Hole 2 Type | Unthreaded |
| Registry OD | 2.189" |
| Registry OD | 55.600mm |
| Mounting Ear Distance 1 | 114.500mm |
| Mounting Ear Distance 1 | 4.508" |
| Tooth Quantity | 10 |
| Arrowhead | SBO0233 |
| Bosch | 0001121422, 0-001-121-422, 0001121423, 0-001-121-423, 0001121427, 0-001-121-427, 0001121428, 0-001-121-428, 0001121443, 0-001-121-443, 0001121444, 0-001-121-444, SR0826X |
| Bosch Aftermarket | SR0826N (New), SR0826X (Reman) |
| Ford | 6G9N11000LA, 6G9N-11000-LA, 6G9N11000LB, 6G9N-11000-LB, 6G9N11000LC, 6G9N-11000-LC, 6G9N11000LD, 6G9N-11000-LD, 6G9NLB, 6G9NLC, 6G9NLD |
| Force | 6G9N-11000-LC |
| J&N Electrical Products | 410-24293 |
| Lester | 19095, 19179 |
| Lucas Electric | LRS02329, LRS2329 |
| Lucas (Europe) | LRS02329 |
| Land Rover | LR002348, LR007022, LR009338, LR017803, LR029180, LR0 17803, LR0 29180 |
| Rover | LR002348, LR007022, LR009338, LR017803, LR029180 |
| PIC | 120-6411 |
| Remy | 17530 |
| WAI | 19095N, 19095N-OG, 19095R |
| IAT | S19095 |
| Xpart Global | XSB19095 |
Thank You for Choosing XPart Engine Electrical Products
At XPart Engine Electrical Products, our goal is 100% customer satisfaction. If you are unsatisfied for any reason and would like to return, exchange, or request a warranty claim, we are happy to assist. Please carefully read the policy below or contact our customer service team.
All items from XPart Inc. include a one (1) year, one-time warranty covering part replacement only.
For returns, exchanges, or warranty service:
Email: info@xpart.ca
Phone: +1 844 44 XPART (97278)
We offer a wide selection of high-quality electrical components and replacement units for:
Available Product Lines: Starters, Alternators, Generators, Hydraulic Motors, and other mobile electrical components.
Overnight shipping is available on most products.
| Make | Model | Engine | Year |
|---|---|---|---|
| Land Rover | LR2 | 3.2L | 2008, 2009, 2010, 2011, 2012 |
| Land Rover | LR2 | 3192cc, 3.2L L6 | 2008, 2009, 2010, 2011 |
| Land Rover Truck | LR2 | L6 3.2L 3192CC | 2010 |
| Land Rover Truck | LR2 | L6 3.2L 3192CC | 2008, 2009, 2010, 2011, 2012 |
| Specification |
|
||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Replacement Part Number |
|
||||||||||||||||||||||||||||||||||||||||
| Why Xpart? |
Installation & Compatibility Tips
|
