Xpart New Starter Motor for Lexus GS460, IS F, IS-F, LS460 — 12V Permanent Magnet Gear Reduction (PMGR), Clockwise Rotation, 9-Tooth High-Torque Gear, 29.8mm Gear OD

Xpart New Starter Motor for Lexus GS460, IS F, IS-F, LS460 — 12V Permanent Magnet Gear Reduction (PMGR), Clockwise Rotation, 9-Tooth High-Torque Gear, 29.8mm Gear OD

Xpart New Starter Motor for Lexus NX200T, RX350, Scion tC, Toyota Camry, Highlander, RAV4, Sienna — 12V (PMGR), Counterclockwise Rotation, 13-Tooth, 40.3mm Gear OD

Xpart New Starter Motor for Lexus NX200T, RX350, Scion tC, Toyota Camry, Highlander, RAV4, Sienna — 12V (PMGR), Counterclockwise Rotation, 13-Tooth, 40.3mm Gear OD

Xpart New Starter Motor for Lexus LX570, Toyota Land Cruiser, Sequoia, Tundra — 12V Planetary Gear Reduction (PLGR), Clockwise Rotation, 9-Tooth, 29mm Gear OD

CAD$285.09
No Online Payment Required
                       Free Same Day Delivery(GTA)
                             Pay Upon Delivery(GTA)
     1 - 2 Days Ontario&Quebec
       2 - 5 Days All Over Canada
Availability:
In stock
SKU
XSD19045

Description

Make Model Engine Year
Lexus LX570 5.7L 2008, 2009, 2010
Lexus LX570 5663cc, 5.7L V8 2008, 2009, 2010, 2011
Lexus LX570 5663cc, 5.7L V8 3URFE 2008, 2009, 2010, 2011
Lexus Truck LX570 V8 5.7L 5663CC 345CID 2008, 2009, 2010, 2011
Toyota LAND CRUISER 5.7L 2008, 2009, 2010
Toyota Land Cruiser 5663cc, 5.7L V8 2008, 2009, 2010, 2011
Toyota Land Cruiser 5663cc, 5.7L V8 3URFE 2008, 2009, 2010, 2011
Toyota Land Cruiser 5700cc, 5.7L V8 2008, 2009, 2010
Toyota SEQUOIA 5.7L 2008, 2009, 2010
Toyota Sequoia 5663cc, 5.7L V8 2008, 2009, 2010, 2011
Toyota Sequoia 5663cc, 5.7L V8 2011
Toyota Sequoia 5663cc, 5.7L V8 3URFBE 2009, 2010, 2011
Toyota Sequoia 5663cc, 5.7L V8 3URFE 2008, 2009, 2010, 2011
Toyota TUNDRA 5.7L 2007, 2008, 2009, 2010
Toyota Tundra 5663cc, 5.7L V8 2007, 2008, 2009
Toyota Tundra 5663cc, 5.7L V8 3URFBE 2009, 2010, 2011
Toyota Tundra 5663cc, 5.7L V8 3URFBE 2011
Toyota Tundra 5663cc, 5.7L V8 3URFE 2007, 2008, 2009, 2010, 2011
Toyota Tundra 5663cc, 5.7L V8 3URFE 2011
Toyota Truck Land Cruiser V8 5.7L 5663CC 345CID 2008, 2009, 2010, 2011

Specification

Lester 19045
Manufacture DENSO (Not OEM)
Family R5.0
Volt 12
Power 2 kw
HP 2.682
Condition New
Rotation Direction Clockwise (Right)
Electric Starter Type Planetary Gear Reduction (PLGR)
Number of Teeth 9
Gear OD 1.142"
Gear OD 29mm
Length 172 mm
Length 6.772"
Mount Hole ID 1 M10x1.25
Mount Hole 1 Type Threaded
Mount Hole ID 2 M10x1.25
Mount Hole 2 Type Threaded
Registry OD 2.906"
Registry OD 73.800mm

Replacement Part Number

Arrowhead ND280-0372, ND280-0402, SND0653
Bosch Aftermarket SR3289X, SR3300X (Reman)
Bosch Service Europe 0-986-UR1-640
Delco DRT0631
DENSO 280-0372, 280-0402, 428000-3960, 428000-3961, 428000-4640, 428000-4641, 428000-396
DENSO Auto Parts 2800402
J&N 410-52469
Lester 19045
IAT S19045
PIC 190-6242
Remy 16096
Toyota 28100-0S010, 28100-0S011, 28100-38040, 28100-38041
WAI 19045N
Xpart Global XSD19045

Why Xpart?

  • All-Terrain Durability: Engineered for reliable, long-lasting performance in the harshest conditions.
  • Reliable Cold Starts: Quality-tested to deliver consistent ignition power in all weather, including freezing temperatures.
  • 100% Brand New & Premium Quality: Not remanufactured or rebuilt; constructed with high-grade materials to meet or exceed OEM durability standards.
  • Easy, Direct-Fit Installation: Designed for a perfect plug-and-play fit—no modifications required.
  • Precision Engineered & Quality Tested: Built and rigorously tested to ensure dependable starting performance and extended lifespan.
  • OEM Compatible: Meets exact factory specifications for seamless integration and optimal function.
  • Built to Last & Warranty-Backed: Heavy-duty construction with premium components plus a 1-year limited replacement warranty for peace of mind.
  • Trusted by Professionals & Vehicle Owners: Our starter motors deliver exceptional value and reliable performance for those who demand the best.
  • Committed to Excellence: We provide premium-quality auto parts designed to fit perfectly, perform flawlessly, and last longer.



Installation & Compatibility Tips

  • Always verify OEM part number and physical dimensions (gear OD, tooth count, mount hole spacing and DE housing) before purchase.
  • Disconnect the negative battery terminal before removing or installing the starter.
  • Inspect flywheel/flexplate teeth and starter mounting flange prior to installation; replace if damaged.
