Xpart New Starter Motor for Lexus NX200T, RX350, Scion tC, Toyota Camry, Highlander, RAV4, Sienna — 12V (PMGR), Counterclockwise Rotation, 13-Tooth, 40.3mm Gear OD

Xpart New Starter Motor for Lexus NX200T, RX350, Scion tC, Toyota Camry, Highlander, RAV4, Sienna — 12V (PMGR), Counterclockwise Rotation, 13-Tooth, 40.3mm Gear OD

Xpart New Starter Motor for Nissan Altima — 12V (PMGR), Counter Clockwise Rotation, 13-Tooth, 1.559

Xpart New Starter Motor for Nissan Altima — 12V (PMGR), Counter Clockwise Rotation, 13-Tooth, 1.559" (39.6mm) Gear OD, M10x1.25 & Unthreaded Mount Holes

Xpart New Starter Motor for Pontiac Vibe, Toyota Corolla, Matrix — 12V Permanent Magnet Gear Reduction (PMGR), Clockwise Rotation, 9-Tooth, 2.913" (74mm) Registry OD

CAD$267.71
No Online Payment Required
                       Free Same Day Delivery(GTA)
                             Pay Upon Delivery(GTA)
     1 - 2 Days Ontario&Quebec
       2 - 5 Days All Over Canada
Availability:
In stock
SKU
XSD19049

Description

Make Model Engine Year
PontiacVIBE1.8L2009
PontiacVibe1795cc, 1.8L L42009
PontiacVibe1798cc, 1.8L L42009, 2010
Pontiac CarVibeL4 1.8L 1798CC 110CID2009, 2010
ToyotaCOROLLA1.8L2009, 2010, 2011
ToyotaCOROLLA1.8L2009, 2010, 2011, 2012, 2013
ToyotaCorolla1794cc, 1.8L L42009
ToyotaCorolla1794cc, 1.8L L42009, 2009, 2010, 2010, 2011, 2011
ToyotaCorolla1794cc, 1.8L L42010, 2011
ToyotaCorolla1794cc, 1.8L L4 1ZZFE2009
ToyotaCorolla1798cc, 1.8L L42011
ToyotaCorolla1798cc, 1.8L L42011, 2012, 2013
ToyotaCorolla1798cc, 1.8L L4 2ZRFE2009, 2010
ToyotaMATRIX1.8L2009, 2010, 2011, 2012
ToyotaMatrix1795cc, 1.8L L42009, 2010, 2011
ToyotaMatrix1798cc, 1.8L L42012
ToyotaMatrix1798cc, 1.8L L4 2ZRFE2009, 2010, 2011
Toyota CarCorollaL4 1.8L 1798CC 110CID2012, 2013
Toyota CarCorollaL4 1.8L 1798CC 110CID2009, 2010, 2011
Toyota CarMatrixL4 1.8L 1798CC 110CID2012, 2013
Toyota CarMatrixL4 1.8L 1798CC 110CID2009, 2010, 2011

Specification

Lester 19049, 19313
Manufacture DENSO (Not OEM)
Case Grounding G
Family R5.0
Volt 12
Power 1.500 kw
HP 2.012
Condition New
Rotation Direction Clockwise (Right)
Electric Starter Type Permanent Magnet Gear Reduction (PMGR)
Number of Teeth 9
Length 149.500 mm
Length 5.886"
Mount Hole ID 1 M10x1.25
Mount Hole 1 Type Threaded
Mount Hole 2 Type Unthreaded
Registry OD 2.913"
Registry OD 74mm
Mounting Ear Distance 1 122mm
Mounting Ear Distance 1 4.803"
Mounting Bolt Hole Quantity 2
Mounting Type Flange

Replacement Part Number

Arrowhead SND0655
Bosch Aftermarket SR3299X (Reman)
DENSO 428000-4300, 428000-4590, 428000-9820, 428000-9830, 428000-430, 428000-4302
DENSO Auto Parts 280-0400
General Motors 88975514, 19205422
J&N 410-52518
Lester 19049, 19313
IAT S19049
PIC 190-6245
Toyota 28100-0T050, 28100-0T051, 28100-37050, 28100-37051, 28100-37052
WAI 19049N
Xpart Global XSD19049

Why Xpart?

  • All-Terrain Durability: Engineered for reliable, long-lasting performance in the harshest conditions.
  • Reliable Cold Starts: Quality-tested to deliver consistent ignition power in all weather, including freezing temperatures.
  • 100% Brand New & Premium Quality: Not remanufactured or rebuilt; constructed with high-grade materials to meet or exceed OEM durability standards.
  • Easy, Direct-Fit Installation: Designed for a perfect plug-and-play fit—no modifications required.
  • Precision Engineered & Quality Tested: Built and rigorously tested to ensure dependable starting performance and extended lifespan.
  • OEM Compatible: Meets exact factory specifications for seamless integration and optimal function.
  • Built to Last & Warranty-Backed: Heavy-duty construction with premium components plus a 1-year limited replacement warranty for peace of mind.
  • Trusted by Professionals & Vehicle Owners: Our starter motors deliver exceptional value and reliable performance for those who demand the best.
  • Committed to Excellence: We provide premium-quality auto parts designed to fit perfectly, perform flawlessly, and last longer.



Installation & Compatibility Tips

  • Always verify OEM part number and physical dimensions (gear OD, tooth count, mount hole spacing and DE housing) before purchase.
  • Disconnect the negative battery terminal before removing or installing the starter.
  • Inspect flywheel/flexplate teeth and starter mounting flange prior to installation; replace if damaged.
