| Make | Model | Engine | Year |
|---|---|---|---|
| Jeep | CHEROKEE | 198cu in, 3.2L V6 | 2015, 2016, 2017, 2018, 2019 |
| Jeep | CHEROKEE | 198cu in, 3.2L V6 | 2016, 2017, 2018, 2019 |
| Jeep | Cherokee | 3.2L V6 | 2020, 2021, 2022 |
| Jeep Truck | Cherokee | V6 3.2L 3239CC 198CID | 2015-2022 |
| Lester | 34008 |
| Manufacture | DENSO (Not OEM) |
| Family | PA70 |
| Volt | 12 |
| Power | 1.200 kw |
| Rotation Direction | Clockwise (Right) |
| Design | PMGR |
| OE Manufacturer | DENSO |
| Number of Teeth | 11 |
| Length | 222 mm |
| Mount Hole ID 1 | M10-1.25 |
| Mount Hole 1 Type | Threaded |
| Mount Hole ID 2 | M10-1.25 |
| Mount Hole 2 Type | Threaded |
| Registry OD | 68mm |
| Housing Rotatable | FALSE |
| Locator Pin | 6mm in Drive End Housing Face |
| Battery Stud | M8-1.25 |
| Start Stop System Compatible | TRUE |
| Case Grounding | G |
| Mounting Bolt Hole Quantity | 2 |
| Mounting Type | Flange |
| Bosch Aftermarket | SR6494X (Reman) |
| Bosch Service Europe | 0-986-CR1-835, 0-986-UR1-835 |
| DENSO | 438000-032, 438000-0321 |
| Chrysler Motors | 56029615AB, 56029615AC, 56029615AD |
| Chrysler | 5602 9615AD, 56029615AB |
| Lester | 34008 |
| Jeep | 56029615AC |
| IAT | S34008 |
| J&N | 410-52674 |
| PIC | 190-6529 |
| Remy | 25036 |
| WAI | 34008N |
| Xpart Global | XSD34008 |
Thank You for Choosing XPart Engine Electrical Products
At XPart Engine Electrical Products, our goal is 100% customer satisfaction. If you are unsatisfied for any reason and would like to return, exchange, or request a warranty claim, we are happy to assist. Please carefully read the policy below or contact our customer service team.
All items from XPart Inc. include a one (1) year, one-time warranty covering part replacement only.
For returns, exchanges, or warranty service:
Email: info@xpart.ca
Phone: +1 844 44 XPART (97278)
We offer a wide selection of high-quality electrical components and replacement units for:
Available Product Lines: Starters, Alternators, Generators, Hydraulic Motors, and other mobile electrical components.
Overnight shipping is available on most products.
| Make | Model | Engine | Year |
|---|---|---|---|
| Jeep | CHEROKEE | 198cu in, 3.2L V6 | 2015, 2016, 2017, 2018, 2019 |
| Jeep | CHEROKEE | 198cu in, 3.2L V6 | 2016, 2017, 2018, 2019 |
| Jeep | Cherokee | 3.2L V6 | 2020, 2021, 2022 |
| Jeep Truck | Cherokee | V6 3.2L 3239CC 198CID | 2015-2022 |
| Specification |
|
||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Replacement Part Number |
|
||||||||||||||||||||||||||||||||||||||||||||
| Why Xpart? |
Installation & Compatibility Tips
|
